51.2v 100ah lifepo4 lithium battery Server Rack battery pack
51.2v 100ah lifepo4 lithium battery Server Rack battery pack offers long life, modular design, real-time monitoring, multiple protections, and remote control via app for reliable performance.
- Category: LiFePO4 Battery
- Tag: lifepo4 battery
Features
· Withstand thermal shock and puncture without fire or explosion
· Compatible with global mainstream brands inverter
· Real-time monitoring on LCD screen
· Communication compatibility: CAN, RS485, RS232
· Built-in 1A active balancer
· Built-in 120A circuit breaker, dual protection
· Modular design, easy to install and maintain, support parallel connection
· Professional BMS, multiple protection
· Up to 3000 cycles, long life
· Can be connected to APP remote control
Specifications
Item | Specifications |
Nominal Voltage | 51.2V |
Nominal Capacity | 105Ah |
Rated Energy | 5376Wh |
Maximum Charge Voltage | 58.4V |
Maximum Charge Current | 50A |
Maximum Continuous Discharge Current | 100A |
Maximum Peak Discharge Current (5 seconds) | 200A |
Discharge Cut-off Voltage | 44.8V |
Charge Temperature | 0~+50℃ |
Discharge Temperature | -20~+65℃ |
Storage Temperature | -20~+45℃ |
Self Discharge (Stored at 50%SOC) | ≤3%/month |
Cycle Life (25℃, 0.5C, 100% DOD) | >3000 |
Terminals | M8 Nut |
Protection Level | IP54 |
Dimensions | 482*450*185mm |
Weight | 44kg |
Communication Protocol | CAN/RS485/RS232 |
Details
